Beskrivelse
Gain Adjustment Range0 to 21 dB (in 3 dB steps)
Battery TypeShure SB900/SB900A Rechargeable Li-Ion or AA batteries 1.5 V
Battery Runtimez
@ 10 mW
Shure SB900Up to 9 hours 20 minutes
AA batteriesUp to 8 hours 40 minutesSee Battery Runtime Chart
Dimensions1136.94 mm x 78.27 mm x 40.77 mm (5.39 in. x 3.08 in. x 1.60 in.) H x W x D
Weight293 g with AA batteries
Operating Temperature Range0°C (32°F) to 45°C (113°F)
HousingMolded Plastic
Audio Input
Microphone Connector6-pin connector for Shure MX405/10/15
ConfigurationUnbalanced
Impedance>20 kO
RF Output
Antenna TypeIntegrated PIFA
Impedance50 O
Occupied Bandwidth<200 kHz
Modulation TypeShure proprietary digital
Power1 mW, 10 mW, 20 mW
See Frequency Range and Output Power table, varies by region
